CEBORA TIG WELDING MACHINE – MODEL: WIN TIG DC 180 M
Applications:
Chemical industry
Light metal fabrication
Handcrafting
Body shop
Routine maintenance
Agricultural industry
| Technical Specifications |  |
|||
|---|---|---|---|---|
| TIG | MMA | |||
 |
230 V 50/60 Hz + 15% / -20% |
400 V 50/60 Hz ± 10% |
Three phase input | |
 |
4 kVA 35% 2,7 kVA 60% 2,2 kVA 100% |
4,6 kVA 30% 3,5 kVA 60% 2,8 kVA 100% |
Input power | |
 |
5 ÷ 180 A | 10 ÷ 140 A | Current adjustment range | |
 |
180 A 35% 135 A 60% 110 A 100% |
140 A 30% 115 A 60% 95 A 100% |
Duty Cycle (10 min.40°C) | |
 |
IP23S |
Protection class | ||
 |
10,3 kg |
Weight | ||
 |
171x420x340 mm |
Dimensions (W x L x H) |
||
Warranty: 2 years
